型號 | 適應 帶寬 mm |
額定 吊高 h mm |
磁場 強度 mT |
物料 厚度 ≤mm |
勵磁 功率 ≤kw |
驅動 功率 ≤kw |
適應 帶速 ≤m/s |
重量 kg |
外形尺寸mm | ||||
A | B | C | D | E | |||||||||
RCDD-5 | 500 | 150 | 70 | 100 | 1 | 1.5 | 4.5 | 950 | 1915 | 882 | 623 | 758 | 1060 |
RCDD-6 | 600 | 175 | 70 | 130 | 1.8 | 1.5 | 1180 | 2045 | 1034 | 623 | 910 | 1200 | |
RCDD-6.5 | 650 | 200 | 70 | 150 | 2 | 2.2 | 1250 | 2174 | 1120 | 664 | 988 | 1290 | |
RCDD-8 | 800 | 250 | 70 | 200 | 3.0 | 2.2 | 1770 | 2423 | 1229 | 677 | 1088 | 1506 | |
RCDD-10 | 1000 | 300 | 70 | 250 | 4.5 | 3.0 | 2380 | 2690 | 1561 | 711 | 1420 | 1730 | |
RCDD-12 | 1200 | 350 | 70 | 300 | 5.8 | 3.0 | 3170 | 2927 | 1720 | 731 | 1580 | 2005 | |
RCDD-14 | 1400 | 400 | 70 | 350 | 6.7 | 4.0 | 4800 | 3500 | 2050 | 1050 | 1800 | 2000 | |
RCDD-16 | 1600 | 450 | 70 | 400 | 9.5 | 5.5 | 5300 | 3900 | 2450 | 1180 | 2200 | 2350 | |
RCDD-18 | 1800 | 500 | 70 | 450 | 12.5 | 7.5 | 6210 | 4400 | 2850 | 1290 | 2600 | 2800 |
